VP-1061 Power Amplifier 60W (301H version)

VP-1061 301H

The VP-1061(301H) power amplifier can be used for rack-mount application.

Specification
* 0 dB = 1 V
Power Source AC: 230 V AC, 50/60 Hz
DC: 24 V DC
Power Consumption AC: 170 W (at rated output), 100 W (EN60065), 14 W (no-signal)
DC: 4.5 A (at rated output), 0.1 A (no-signal)
Rated Output 60 W
Input 2 program inputs (parallel), 0 dB*, 20 kΩ, balanced
2 priority inputs (parallel), 0 dB*, 20 kΩ, balanced
Impedance 167 Ω (100 V)
S/N Ratio 80 dB or more
Total Harmonic Distortion 1 % or less (at rated output f = 1 kHz)
Frequency Response 80 Hz - 16 kHz, ±3 dB (at 1/3 rated output)
Ventilation Fan cooling
Operating Temperature 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)
Operating Humidity 90 %RH or less (no condensation)
Finish Panel: Aluminum, black, alumite
Dimensions 210 (W) × 88.4 (H) × 338.7 (D) mm (8.27" × 3.48" × 13.33")
Weight 6.9 kg (15.21 lb)
Accessory Power cable (2 m (6.56 ft)) …1, Removable terminal plug (2 pins) …2,
Removable terminal plug (3 pins) …2, Removable terminal plug (5 pins) …2,
Joint plate …1, Joint plate mounting screw …3, Fuse (1.25 A) …1
Option Fault detector: YA-1000A
Half width blank panel: MB-25B-BK (for rack mounting one VP-1061 unit)
Rack joint bracket: MB-25B-J (for rack mounting two VP-1061 units)
