VP-1061 Power Amplifier 60W (CE version)
VP-1061 CE
The VP-1061 power amplifier can be used for rack-mount application.
- * 0 dB = 1 V
| Power Source | AC: 220 - 230 V AC, 50/60 Hz DC: 24 V DC |
|---|---|
| Power Consumption | AC: 170 W (at rated output), 100 W (EN60065), 14 W (no-signal) DC: 4.5 A (at rated output), 0.1 A (no-signal) |
| Rated Output | 60 W |
| Input | 2 program inputs (parallel), 0 dB*, 20 kΩ, balanced 2 priority inputs (parallel), 0 dB*, 20 kΩ, balanced |
| Impedance | 167 Ω (100 V) |
| S/N Ratio | 80 dB or more |
| Total Harmonic Distortion | 1 % or less (at rated output f = 1 kHz) |
| Frequency Response | 80 Hz - 16 kHz, ±3 dB (at 1/3 rated output) |
| Ventilation | Fan cooling |
| Operating Temperature | 0 ℃ to +40 ℃ (32 ゜F to 104 ゜F) |
| Operating Humidity | 90 %RH or less (no condensation) |
| Finish | Panel: Aluminum, black, alumite |
| Dimensions | 210 (W) × 88.4 (H) × 338.7 (D) mm (8.27" × 3.48" × 13.33") |
| Weight | 6.9 kg (15.21 lb) |
| Accessory | Power cable (2 m (6.56 ft)) …1, Removable terminal plug (2 pins) …2, Removable terminal plug (3 pins) …2, Removable terminal plug (5 pins) …2, Joint plate …1, Joint plate mounting screw …3, Fuse (1.25 A) …1 |
| Option | Fault detector: YA-1000A Half width blank panel: MB-25B-BK (for rack mounting one VP-1061 unit) Rack joint bracket: MB-25B-J (for rack mounting two VP-1061 units) |
