BG-1030 Modular Mixer Amplifier
BG-1030
The BG-1030 is a Mixer Power Amplifier and can mix up to a total of 5 independent input signals. Power output is rated at 30 W, and this is ideal for use in sound systems requiring small power outputs.
- (*1) 0 dB = 1 V
| Power Source | 120 V AC, 60 Hz |
|---|---|
| Rated Output | 30 W |
| Power Consumption | 80 W (rated output), 60 W (based on UL/CSA standards) |
| Frequency Response | 50 - 20,000 Hz |
| Total Harmonic Distortion | 0.05%, at 1 kHz, rated output |
| Input | Mic: -60 dB (*1), 600 Ω, electrically-balanced, M3 screw terminal (*2) Tel: -20 dB (*1), 10 kΩ/600 Ω, balanced, M3 screw terminal (*2) Program: -10 dB (*1), 10 kΩ, electrically-balanced, M3 screw terminal (*2) Aux: -10 dB (*1), 47 kΩ, unbalanced, 2 P RCA pin jack (internal mixing) Module: -20 dB (*1), 10 kΩ, unbalanced, card edge connector Power IN: 0 dB (*1), 10 kΩ unbalance, RCA pin jack Mute: M3 screw terminal (*2) |
| Output | Main: 4 Ω, 25 and 70 V, balanced, M3 screw terminal (*2) Sub: 1 W/8 Ω, unbalanced, M3 screw terminal (*2) MOH: 0 dB(*1), 600 Ω, balanced, M3 screw terminal (*2) Preamp OUT: 0 dB (*1), 600 Ω unbalance, RCA pin jack |
| Output Regulation | Under 2 dB, no load to full load |
| S/N Ratio | Mic: 60 dB, Tel: 75 dB, Program: 75 dB, Aux: 75 dB, Module: 75 dB (Band Pass: 20 - 20,000 Hz, Tone Controls: Centered) |
| Tone Controls | Bass: ±10 dB at 100 Hz, Treble: ±10 dB at 10 kHz Controls affect only program input, aux input and module (BGM) input |
| Indicator | Power LED, Signal LED, Peak LED |
| Protection | Self protection, with 1 AC breaker (outside) |
| Other Feature | Automatic electronic drive limiter Output disconnected for approx. 3 seconds after the unit is turned on |
| Finish | Panel: ABS resin, black Case: Steel plate, black, paint |
| Dimensions | 264 (W) × 107.4 (H) × 280 (D) mm |
| Weight | 4.8 kg (without input module) |
| Accessory | Volume control covers ……5 |
- (*2) Distance between barriers on the above screw terminal: 6 mm
